| 性能 | 抗张强度 | 伸张性 | 撕裂强度 | 体积电阻率 | 介电强度 | 介电常数 | 介质损耗角正切 | 阻燃性 | 使用温度范围 |
| MPa{Kg/cm2} | % | KN/m{Kg f/cm} |
Ω.m
{Ω.cm}
|
KV/mm | 50Hz | 50Hz | UL-1441 | (℃) | |
| 阻燃性 | 6.9{70} | 400 | 24.5{25} |
2x10^12
2x10^14
|
25 | 3.2 | 0.001 | VW-1 | -50~+200 |
| 普通型 | 6.9{70} | 400 | 24.5{25} |
2x10^12
2x10^14
|
25 | 3.2 | 0.001 | —— | -50~+200 |
| 内径mm | 壁厚mm | 包装 | ||||
| 标准 | 公差 | 2.5KV | 4KV | 6KV | 7KV | M/R |
| 0.5 | ±0.2 | 0.25 | 200 | |||
| 1.0 | ±0.2 | 0.50 | 1.00 | 1.50 | 2.00 | 200 |
| 1.5 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 200 |
| 2.0 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 200 |
| 2.5 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 200 |
| 3.0 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 3.5 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 4.0 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 4.5 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 5.0 | ±0.3 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 6.0 | ±0.5 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 7.0 | ±0.5 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 8.0 | ±0.5 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 9.0 | ±0.5 | 0.50 | 1.00 | 1.50 | 2.00 | 100 |
| 10.0 | ±0.5 | 0.50 | 1.00 | 1.50 | 2.00 | 50 |
| 11.0 | ±0.5 | 1.00 | 1.50 | 2.00 | 50 | |
| 12.0 | ±0.5 | 1.00 | 1.50 | 2.00 | 50 | |
| 13.0 | ±0.5 | 1.00 | 1.50 | 2.00 | 50 | |
| 14.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 15.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 16.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 17.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 18.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 19.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
| 20.0 | ±0.6 | 1.00 | 1.50 | 2.00 | 50 | |
